Kettentyp |
Teilung |
lichte Weite |
Rollen-Ø |
Bolzen-Ø |
Bolzenlänge |
Laschen-höhe |
Laschen- dicke |
Min. Bruchkraft |
Mittlere Bruchkraft |
Gewicht / Meter |
||
|
Chain type |
Pitch |
Inner width |
Roller – Ø |
Pin – Ø |
Pin length |
Plate height |
Plate thickness |
Min. tensile strength |
Average tensile str. |
Weight / meter |
||
|
ISO |
P [mm] |
b1 min. [mm] |
d1 max. [mm] |
d2 max. [mm] |
L max. [mm] |
Lc max. [mm] |
h2 max. [mm] |
t [mm] |
T [mm] |
FU [kN] |
FB [kN] |
q [kg/m] |
|
CA 550 |
41,400 |
19,81 |
16,87 |
7,19 |
35,0 |
38,5 |
20,20 |
2,80 |
2,80 |
39,10 |
51,2 |
1,94 |
|
CA 550 V |
41,400 |
19,05 |
16,80 |
8,28 |
36,1 |
39,1 |
22,00 |
3,00 |
3,00 |
55,00 |
68,1 |
2,24 |
|
CA 555 |
41,400 |
12,70 |
16,87 |
7,19 |
29,1 |
32,0 |
19,30 |
3,10 |
3,10 |
39,10 |
56,0 |
1,72 |
|
CA 557 |
41,400 |
20,24 |
17,78 |
8,00 |
37,4 |
40,6 |
23,10 |
3,10 |
3,10 |
55,61 |
74,3 |
2,60 |
|
CA 620 |
42,010 |
24,51 |
17,91 |
7,19 |
41,8 |
45,2 |
20,20 |
3,25 |
3,25 |
39,10 |
55,1 |
2,35 |
|
CA2060 H |
38,100 |
12,70 |
11,91 |
5,94 |
29,2 |
31,6 |
18,00 |
3,25 |
3,25 |
31,10 |
40,5 |
1,45 |
|
CA2063 H |
38,100 |
12,70 |
11,89 |
5,94 |
29,4 |
34,2 |
19,30 |
3,25 |
3,25 |
31,28 |
40,5 |
1,65 |
|
CA550 F4 |
41,400 |
20,24 |
14,35 |
7,14 |
35,0 |
38,5 |
19,05 |
2,80 |
2,80 |
50,00 |
52,0 |
1,76 |
|
CA550 F5 |
41,400 |
20,24 |
16,66 |
7,14 |
35,0 |
38,5 |
19,05 |
2,80 |
2,80 |
45,00 |
52,0 |
1,97 |
|
CAE44151 |
28,575 |
16,20 |
15,88 |
7,92 |
33,5 |
36,9 |
22,20 |
3,25 |
3,25 |
58,80 |
64,5 |
2,73 |
|
38.4R |
38,400 |
19,05 |
15,88 |
6,92 |
33,8 |
36,4 |
17,30 |
2,50 |
2,50 |
33,00 |
41,2 |
1,70 |
|
38.4V |
38,400 |
18,00 |
15,88 |
6,92 |
35,0 |
38,0 |
17,30 |
3,00 |
3,00 |
40,00 |
50,0 |
1,83 |
|
38.4VB |
38,400 |
19,05 |
15,88 |
8,28 |
36,1 |
39,4 |
20,50 |
3,00 |
3,00 |
50,00 |
62,5 |
2,17 |
|
55VD |
41,400 |
23,00 |
17,90 |
8,22 |
39,3 |
42,4 |
20,00 |
2,80 |
2,80 |
42,00 |
45,0 |
2,34 |
|
S62F3 |
41,910 |
25,40 |
19,05 |
8,00 |
42,0 |
44,6 |
26,00 |
3,00 |
3,00 |
47,00 |
58,7 |
3,12 |
|
CA 960 |
41,400 |
22,61 |
17,78 |
8,90 |
40,1 |
43,0 |
23,10 |
3,00 |
3,00 |
66,00 |
72,6 |
6,94 |
|
CA550VF2 |
41,400 |
19,05 |
16,80 |
8,28 |
36,1 |
36,8 |
20,00 |
3,00 |
3,00 |
55,00 |
68,7 |
2,13 |
|
CA550 H |
41,400 |
20,00 |
16,74 |
7,14 |
36,0 |
39,1 |
19,10 |
3,00 |
3,00 |
57,82 |
60,8 |
2,00 |
